P. 46

Shed & Barn Hardware








                                               STANDARD TEE HINGES
                                                 SIZE INS (MM)   FINISH   QTY PER BOX  BULK CODE  QTY PER BOX  PRE-PACKED CODE
                                                 4” (100)   Galvanized   10/100   004 100 1   10/100     050 100 1
                                                 4” (100)    Zinc      10/100    004 100 2    10/100     050 100 2
                                                 4” (100)   Super Black   10/100   004 100 3    10/100   050 100 3
                                                 6” (150)   Galvanized   10/60   004 150 1    5/30       050 150 1
                                                 6” (150)    Zinc      10/60     004 150 2    5/30       050 150 2
                                                 6” (150)   Super Black   10/60   004 150 3    5/30      050 150 3
                                               Galvanized hinges have brass pins. See more sizes on page 30
                                               ESTATE TEE HINGES
                                                 SIZE INS (MM)      FINISH   PAIRS PER BOX  FASTENERS   CODE
                                                 8” (200)        Super Black     5/20     2” hexscrew  004 202 3
                                               Packed in polythene sleeves - including screws. See more sizes on page 30-31
                                               HEAVY REVERSIBLE HINGES
                                                 SIZE INS (MM)      FINISH        PAIRS PER BOX        CODE
                                                 10” (250)        Galvanized           5             509 250 1
                                                 10” (250)          Black              5             509 250 3
                                                 12” (300)        Galvanized           5             509 300 1
                                                 12” (300)          Black              5             509 300 3
                                               See more sizes on page 3
                                               PULL HANDLE
                                                 SIZE INS (MM)      FINISH         QTY PER BOX         CODE
                                                 8” (200)         Galvanized         10/100          147 175 1
                                                 8” (200)           Zinc             10/100          147 175 2
                                                 8” (200)        Super Black         10/100          147 175 3
                                               Packed in polythene sleeves - including screws

                                               LOCKING T-HANDLES
                                                 SIZE INS (MM)   FITS DOOR SIZE   FINISH   QTY PER BOX   CODE
                                                 3 1/2” (89)         1-2”      Chrome       50        800 089 4
                                                 3 1/2” (89)         1-2”       Black       50        800 089 3
                                                 4” (100)         1 3/4-2 3/4”   Chrome     50        800 100 4
                                                 4” (100)         1 3/4-2 3/4”   Black      50        800 100 3
                                                4 1/2” (112)      2 3/4-3 3/4”   Chrome     50        800 112 4
                                                4 1/2” (112)      2 3/4-3 3/4”   Black      50        800 112 3
                                                5 1/2” (137)      3 3/4-4 3/4”   Chrome     50        800 137 4
                                                5 1/2” (137)      3 3/4-4 3/4”   Black      50        800 137 3
                                                 6” (150)         4 3/4-5 3/4”   Chrome     50        800 150 4
         Keyed differently. Keyed alike available.
         Master key available. Includes 1 keyset,     6” (150)    4 3/4-5 3/4”   Black      50        800 150 3
         Spare Keysets available. Does not include    6 3/4” (172)   5 3/4-6 3/4”   Chrome   50       800 162 4
         inside door handle.                    6 3/4” (172)      5 3/4-6 3/4”   Black      50        800 162 3
