Standard Gate Components









        STANDARD COMPONENTS

                                               STANDARD TEE HINGES
                                                 SIZE INS (MM)   FINISH     QTY PER BOX    CODE   PRE-PACKED CODE
                                                  3” (75)      Galvanized     10/100     004 075 1
                                                  3” (75)        Zinc         10/100     004 075 2
                                                  3” (75)        Black        10/100     004 075 3
                                                 4” (100)      Galvanized     10/100     004 100 1
                                                 4” (100)        Zinc         10/100     004 100 2
                                                 4” (100)        Black        10/100     004 100 3
                                                 6” (150)      Galvanized      10/60     004 150 1
                                                 6” (150)        Zinc      10/60 (5/30 PP)  004 150 2    050 150 2
                                                 6” (150)        Black     10/60 (5/30 PP)  004 150 3    050 150 3
                                                 8” (200)      Galvanized      10/30     004 200 1
                                                 8” (200)        Zinc          10/30     004 200 2
                                                 8” (200)        Black         10/30     004 200 3
                                                 10” (250)     Galvanized      10/30     004 250 1
                                                 10” (250)       Zinc          10/30     004 250 2
                                                 10” (250)       Black         10/30     004 250 3
                      PRE-PACKED
                                               Galvanized hinges have brass pins . Pre-packed hinges come with screws.
                                               HD STANDARD TEE HINGES  HEAVY DUTY
                                                 SIZE INS (MM)    FINISH      QTY PER BOX   CODE   PRE-PACKED CODE
                                                 6” (150)         Zinc          10/40     004 155 2
                                                 6” (150)         Black     10/40 (10/20 PP)  004 155 3    050 155 3
                                               SQUARE TEE HINGE
                                                 SIZE INS (MM)    FINISH      QTY PER BOX   CODE   PRE-PACKED CODE
                                                 6” (150)         Zinc      10/60 (5/30 PP)  602 150 2    052 150 2
                                                 6” (150)         Black     10/60 (5/30 PP)  602 150 3    052 150 3
                                               Pre-packed hinges come with #10 x 1 1/2” screws.

                                               OFFSET HINGES
                                                 SIZE INS (MM)    FINISH      QTY PER BOX   CODE   PRE-PACKED CODE
                                                 3 1/2” (89)    Galvanized      10/60     602 001 1
                                                 3 1/2” (89)      Zinc          10/60     602 001 2
                                                 3 1/2” (89)      Black     10/60 (5/30 PP)  602 001 3    052 001 3
                                               Galv. hinges have brass pins. Pre-packed hinges come with black 1/4 x 2” hex screws.
                                               ESTATE TEE HINGES
               8” 0042023                        SIZE INS (MM)      FINISH        PAIRS PER BOX        CODE
                               10” 0042523
                               12” 0043023       8” (200)           Black             5/20            004 202 3
                                                 10” (250)          Black             5/15            004 252 3
                                                 12” (300)          Black             5/10            004 302 3
                                               Packed in polythene sleeves - including screws. 10” and 12”have 3” carriage bolts
                                               for gate and 3” hex screws for post. 8” has 2” hex screws.
