P. 38
Standard Gate Components
PULL HANDLE
SIZE INS (MM) FINISH QTY PER BOX CODE
8” (200) Galvanized 10/100 147 175 1
8” (200) Zinc 10/100 147 175 2
8” (200) Super Black 10/100 147 175 3
Packed in polythene sleeves - including screws
GATE HANDLE
SIZE INS (MM) FINISH QTY PER BOX CODE
8” (200) Black 10/100 147 200 3
Fasteners included
ROUNDED GATE HANDLE
SIZE INS (MM) FINISH QTY PER BOX CODE
6” (150) Black 10/100 147 150 3
Stainless Steel Fasteners included
THUMB HANDLE
SIZE INS (MM) FINISH QTY PER BOX CODE
10 1/2” (255) Super Black 10/100 602 008 3-A
GATE RETURN SPRING
SPRING LENGTH FINISH QTY PER BOX CODE
8” (200) Zinc 10/40 526 200 2
8” (200) Super Black 10/40 526 200 3
10” (250) Zinc 10/40 526 250 2
10” (250) Super Black 10/40 526 250 3
Packed in polythene sleeves - including screws
J BOLT HANGER
SIZE INS (MM) FINISH QTY PER BOX CODE
6” x 5/8” (150) Zinc 10/50 601 658 2
10” x 5/8” (250) Zinc 10/50 601 108 2
10” x 5/8” (250) Galvanized 10/50 601 108 1
ADJUSTABLE EYE BOLT
SIZE INS (MM) FINISH QTY PER BOX CODE
6” x 5/8” (150) Zinc 10/50 049 616 2
BARREL BOLTS
SIZE INS (MM) FINISH QTY PER BOX CODE
4” (100) Galvanized 10/100 602 100 1
4” (100) Zinc 10/100 602 100 2
4” (100) Super Black 10/100 602 100 3
Packed in polythene sleeves - including screws
34
